ADVANTAGES:
1. One-piece structure (combined pressure pump and test chamber); easy to operate and more accurate test results;
2. The diaphragm is pressurized; the pressure is large, the pressure is maintained for a long time, the maintenance is convenient, and the test cost is also greatly reduced;
3. Completely made of stainless steel also makes it more beautiful and durable.
APPLICATION: It is used to measure the water flow per unit time of the drainage network.
STANDARDS: ISO12958, ASTM4716, GBT 17633-1998
TECHNICAL PARAMETERS:
1. Sample size: 300 × 300mm
2. Water level pressure difference: 60, 150, 300 mm (arbitrary adjustment)
3. Maximum pressurization: ≤0.5±1.6%Mpa
5. Power: 220V, 50Hz, 500W
6. Dimensions: 900×500×1300mm (L×W×H)
7. Mass: 90Kg
