APPLICATION:

According to the bending force of the sample, select the appropriate initial spacing and weight to make reciprocating folding - resistant movement at a certain frequency to test the quality of belt products such as waistband, back strap and soft lifting handle.

STANDARDS: QBT 5246 - 2018 and other standards.

Instrument characteristics:

1. The casing of the whole machine is made of high-quality metal baking varnish, which is elegant and easy to clean and maintain.

2. The instrument is driven by motor, with stable speed, low noise and high stability.

3. The table top of the sample is made of imported special aluminum. The material is light, the surface is bright and clean, and it will never rust.

4. The instrument adopts imported special aluminum wire drawing panel, equipped with metal keys, which is sensitive to operation and not easy to damage.

5. Large screen color touch screen display operation.

Technical parameters:

1. Sample group: 2 groups

2. Initial spacing: ( 30,35,40 ) mm ( optional )

3. Maximum stroke: 30-60mm ( adjustable )

4. Folding endurance frequency: 30 - 60 times /min ( adjustable )

5. Folding endurance: 0 - 999999 times ( adjustable )

6. Weight: ( 0.5, 2, 4, ) kg

7. Volume: length 700mm× width 420mm× height 520 mm.

8. Weight: about 90kg

9. Power supply: 220V, 50Hz
